NSPV IP67 Waterproof Photovoltaic Mini Solar Branch Connectors For Solar System Connection

Product Details:

Material PPE/PA(Insulation material)
Operating Temperature -40-+85 Celsius (oC)
Output Voltage 1500 Volt (V)
Color Black
Share Your Product:

Get a Price/Quote

Request To Call Back Send Inquiry

NSPV IP67 Waterproof Photovoltaic Mini Solar Branch Connectors For Solar System Connection Price And Quantity

Minimum Order Quantity 100 Pair

NSPV IP67 Waterproof Photovoltaic Mini Solar Branch Connectors For Solar System Connection Product Specifications

Operating Temperature -40-+85 Celsius (oC)
Material PPE/PA(Insulation material)
Color Black
Output Voltage 1500 Volt (V)

NSPV IP67 Waterproof Photovoltaic Mini Solar Branch Connectors For Solar System Connection Trade Information

FOB Port EXW
Supply Ability 5000 Pair Per Month
Delivery Time Days
Sample Available Yes
Sample Policy Sample costs shipping and taxes has to be paid by the buyer
Packaging Details Standard packing
Main Domestic Market All India

Product Description

L Mini Connector T Type

Product Specifications
Insulation material	PPE/PA	Safety degree	II
Rated current	20A	Flame class	UL94-V0
Rated voltage	1500V DC	Insertion force/Withdrawal force	less than 50N / more than 50N
Test voltage	8kV(50Hz,Imin)	Ambient temperature range	-40...+85(IEC)
Typical contact resistance	less than 0.25 mohm	Suitable cable cross sections	1.5-4mm2/16-12AWG
Contact material	Copper,Tin plated	Connecting system	Crimp connection
Degree of protection	IP67	Nut cap locking force	1-1.5Nm
Cable O.D. size Max.(mm)	6.2	Upper limiting temperature	110(IEC)
