TUV Certified IP68 Waterproof MC 4 Solar Cable Connector 1500VDC 4mm² 6mm² Contact Pins

Product Details:

Share Your Product:

0.85 USD ($)/Set

Get a Price/Quote

Request To Call Back Send Inquiry

TUV Certified IP68 Waterproof MC 4 Solar Cable Connector 1500VDC 4mm² 6mm² Contact Pins Price And Quantity

Price 0.85 USD ($)/Set
Price Range 0.85 - 1.50 USD ($)/Set
Minimum Order Quantity 500 Set

TUV Certified IP68 Waterproof MC 4 Solar Cable Connector 1500VDC 4mm² 6mm² Contact Pins Trade Information

FOB Port EXW
Payment Terms Telegraphic Transfer (T/T)
Sample Policy Contact us for information regarding our sample policy
Packaging Details Standard packing
Main Export Market(s) Asia Australia Central America North America South America Eastern Europe Western Europe Middle East Africa
Main Domestic Market All India
Certifications TUV

Product Description

1500VDC PV4.0 Solar connector with 4/6sqmm cable

Feature: Suitable for 4/6sqmm cable; Matching MC4/EVO connector; TUV certified; IP68; High voltage; High current.

Solar 1500VDC 4/6sqmm cable connector:
1500VDC, 35A; Low contact resistance; Suitable for 4/6sqmm & 10/12AWG cable.

Product Specifications
Insulation material	PPE/PA	Safety degree	II
Rated voltage	1500VDC	Flame class	UL94-V0
Rated impulse voltage	12KV	Installation type	Outdoor, UV resistant(F1)
Test voltage	8KV(50Hz,1min)	Ambient temperature range	-40„...+85„(IEC)
Contact resistance	‰0.25mÎ	Suitable cable cross sections	1.5-10mm²/16-8AWG
Degree of protection	IP68(1m,1H)	Nut cap locking force	1.5-1.8Nm
Overvoltage category/Pollution degree	CATIII/2	Upper limiting temperature	110„(IEC)
Regulatory approval	TUV/CE(IEC62852:2014)	Rated impulse voltage	16KV
