1500VDC 50A Solar Panel Fuse Connectors Male Connector IP68 Waterproof With TUV Certificate For Combiner Box

1500VDC 50A Solar Panel Fuse Connectors Male Connector IP68 Waterproof  With TUV Certificate For Combiner Box

Product Details:

  • Product Type Other
  • Material PPE/PA(Insulation material)
  • Operating Temperature -40-+85 Celsius (oC)
  • Max Voltage 1575 Volt (V)
  • Output Voltage 1500 Volt (V)
  • Size 13.9*2.9*2.9
  • Dimension (L*W*H) 13.9*2.9*2.9 Centimeter (cm)
2.68 USD ($)/Piece
X

1500VDC 50A Solar Panel Fuse Connectors Male Connector IP68 Waterproof With TUV Certificate For Combiner Box Price And Quantity

  • 1000 Piece
  • 2.68 USD ($)/Piece

1500VDC 50A Solar Panel Fuse Connectors Male Connector IP68 Waterproof With TUV Certificate For Combiner Box Product Specifications

  • 1575 Volt (V)
  • Other
  • 0.075 Kilograms (kg)
  • 1500 Volt (V)
  • PPE/PA(Insulation material)
  • -40-+85 Celsius (oC)
  • 13.9*2.9*2.9
  • 13.9*2.9*2.9 Centimeter (cm)
  • Black

1500VDC 50A Solar Panel Fuse Connectors Male Connector IP68 Waterproof With TUV Certificate For Combiner Box Trade Information

  • EXW
  • 1000000 Piece Per Year
  • Days
  • Yes
  • Sample costs shipping and taxes has to be paid by the buyer
  • Standard packing
  • All India
  • TUV

Product Description

1500VDC PV 4.0 Panel Fuse Connector

Product Specifications:

  • Insulation material:PPE/PA
  • Fuse Specification:1A-50A
  • Rated current(Without fuse):50A
  • Safety degree:II
  • Rated voltage:1500VDC
  • Flame class:UL94-V0
  • Maximum voltage(With fuse):1575V
  • Ambient temperature range:-40-+85(IEC)
  • Contact resistance: less than0.25 mohm
  • Upper limiting temperature:110(IEC)
  • Contact material:Copper,Tin plated
  • Suitable cable cross sections:2.5-16mm2/14-6AWG
  • Degree of protection:IP68(1m,1H)
  • Suitable for fuse size(mm):10X85 or 10/14X85
  • Rated Impulse voltage: 12KV
  • Regulatory approval:TUV, CE
